Sterilizing Equipments

Construction : The unit has outer chamber, inner Chamber, Boiler, Lid and Jacket - all made of stainless Steel. For controlling sterilization cycle, a three way valve or a multiport valve - made of S.S. is provided. It is supplied complete with vacuum breaker, water level indicator, steam trap and automatic pressure control switch. The whole unit is mounted on a robust tubular stand. It is available in the following standard sizes. Operatable on 3 Phase, 440 Volts A.C. Supply.

Mode of Heating : Electrically heated by special flange type/immersion type heaters, to work on 440 volts three phase 50 cycles.

Working Pressure : The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g ( 15 psi - 17 psi ).

Working Temperature : 121° C

Hydrotest Pressure : 2.5 kgf/cm sq.g ( 35 psi )

Construction : The unit has inner Chamber, Boiler, Lid and Jacket - all made of stainless Steel, outer chamber of thick gauge mild steel. For controlling sterilization cycle, a three way valve or a multiport valve - made of S.S. is provided. It is supplied complete with vacuum breaker, water level indicator, steam trap and automatic pressure control switch. The whole unit is mounted on a robust tubular stand. It is available in the following standard sizes. Operatable on 3 Phase, 440 Volts A.C. Supply.

Mode of Heating : Electrically heated by special flange type/immersion type heaters, to work on 440 volts three phase 50 cycles.

Working Pressure : The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g ( 15 psi - 17 psi ).

Working Temperature : 121° C

Hydrotest Pressure : 2.5 kgf/cm sq.g ( 35 psi )

Construction : Triple walled construction, all the three walls are made of thick high grade stainless steel sheet. The lid is made of stainless steel sheet. The unit is fitted with radial locking system with paddle lifting device, made of MS chrome plated. Provided with built- in safety valve, pressure gauge, pressure release valve and water level indicator. The pressure is adjustable from 5 psi to 20 psi with automatic pressure control switch, which controls the pressure with an accuracy of +/- 1 psi. Supplied complete with stainless steel basket, chord and plug.

Mode of Heating : Electrically heated by special flange type/immersion type heaters, to work on 220 volts single phase 50 cycles.

Working Pressure : The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g ( 15 psi - 17 psi ).

Working Temperature : 121° C

Hydrotest Pressure : 2.5 kgf/cm sq.g ( 35 psi )
