Catheter is made from Medical Grade Virgin PTFE (Teflon is of Internationally accepted high quality.
PTFE Tubing-The Most Bio- Compatible Material, with longer indwelling time.
PTFE has lowest co-efficient of friction, thereby smoothening the insertion.
Injection port with silicon valve for intermittent medication.
Sharp 3 facet bevel with back cut Japanese needle.
Colour coded cap for easy gauge identification.
Sharp 3 facet bevel with back cut Japanese needle to reduce the penetration force.

Gauge Specifications

	Gauge	OD m.m.	Length	Flow Rate ml/min.
Orange	14G	2.10	45	290
Medium Grey	16G	1.70	45	176
White	17G	1.50	45	130
Deep Green	18G	1.30	45	76
Pink	20G	1.00	33	54
Deep Blue	22G	0.85	25	31
Yellow	24G	0.70	19	14
Violet	26G	0.60	19	13

Prod. Code: TIDP.3860

IV Cannula With Wings and Without Port

IV Cannula with wings without port for infants with a detachable collar on the wings which provides support and facilitates the easy insertion into an infants body. The collar can then be removed thus making the Cannula flat for fixing on the body and avoids any interference with the body or accidental removal of Cannula when the baby moves.

Our I.V. Cannula Range has Needle cover to protect the needle from accidental damage or punctures. Hub Cover i.e., the flashback chamber has high visibility indicating perfect and successful veni-puncture with blood entry. Needles Hub has a holding area precisely designed for placement of thumb.

Leur Lock also called stopper used to plug the cannula to prevents any seepage of blood due to back flow, when cannula is not in use. Easy to peel off system to remove form skin blister pack.

Gauge Specifications

Colour Code		Gauge	OD m.m.	Length	Flow Rate ml/min.
	Yellow	24G	0.70	19	14
	Violet	26G	0.60	19	13

Prod. Code: TIDP.3880

IV Cannula Without Wings and Without Port

IV Cannula without wing without port can be used for simple procedures where injection of medicine is not required during infusion.

Our I.V. Cannula Range has Needle cover to protect the needle from accidental damage or punctures. Hub Cover i.e., the flashback chamber has high visibility indicating perfect and successful veni-puncture with blood entry. Needles Hub has a holding area precisely designed for placement of thumb. Leur Lock also called stopper used to plug the cannula to prevents any seepage of blood due to back flow, when cannula is not in use. Easy to peel off system to remove form skin blister pack.

Sterilzation is done with Ethylene Oxide gas.
